| Model |
Go-Chair |
| Weight Capacity |
300 lbs. |
| Turning Radius1 |
25.4" with foot platform |
| Width1 |
22.6" |
| Length1,2 |
28.5" without front rigging
33" with front rigging |
| Maximum Speed3 |
up to 3.7 mph |
| Ground Clearance1 |
1.6" at anti-tip
1.9"at frame |
| Front Wheels |
6" solid casters |
| Drive Wheels |
9" solid |
| Rear Wheels |
3" solid anti-tips |
| Standard Electronics |
40 amp, PG GC3 (non-programmable) |
| Battery Size (2 required) |
18 Ah, 12 V, deep-cycle |
| Standard Battery Charger |
Off-board, 2 amp |
| Per-Charge Range3,11 |
Up to 8.74 miles |
| Battery Weight9 |
14 lbs. each |
| Weight of Heaviest Piece5 |
36 lbs. (rear) |
| Standard Seat Weight |
30 lbs. |
| Standard Seat Size |
Compact, Foldable (18"x17") |
| Medicare Code Coverage |
K0899 Power Mobility Device, not coded by DME PDAC or does not meet criteria |
| Warranty |
5-Lifetime limited on frame;
13- month limited on electronics;
13- month limited on drive motors |
| Notes |
1Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of + or - 3 %. Dimensions listed are for power base only. Overall measurements will vary based on seating and accessory selections.
2Without front riggings.
3Varies with user weight, terrain, battery type, battery condition and tire pressure.
5Does not include seat or battery weights.
9Battery weight may vary based on manufacturer.
11Tested in accordance with ANSI/RESNA, WC Vol. 2, Section 4 and ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Testing conducted at maximum weight capacities. This specification can be subject to a variance of +10%, -5%. |
