F5 Corpus VS


With the F5 Corpus VS, there are no compromises. We combined all of the features of the world-renown Corpus seating system, along with standing functionality. With the F5 Corpus VS, users may stand and drive at any point of the stand sequence, and the redesigned chest bar offers added comfort and stability. The F5 Corpus VS provides an array of benefits from social interactions like being able to talk to someone face-to-face to positive health outcomes like greater pressure relief and improve circulatory, GI and respiratory systems.

The CORPUS® SEATING SYSTEM. We retained all of the things that you have come to expect from the legendary Corpus seating system like the open armrest design and the UniTrack System. Then, we took the Corpus seating system to the next level with advanced features such as: programmable legrest articulation, 14” seat elevator and the A/P tilt function, which provides 50º of posterior tilt as well as any degree of anterior tilt including full stand angle. The A/P tilt helps our users with transfers, added reach, and allows them to get closer to a table or workspace.

f5-suspension

FULLY INDEPENDENT SUSPENSION

A true fully independent suspension allows the F5 Corpus VS to absorb everyday terrain and obstacles with minimal translation to the user. Our updated shocks are fully adjustable with an included 4mm tool, all while the user remains in the chair. The ride quality is like nothing you’ve experienced in a power wheelchair before.

f5-suspension

REDEFINING SUPPORT

The chest bar and knee blocks on the F5 Corpus VS have been completely redesigned for comfort and accessibility. With features like simplified adjustment points and quick release mechanisms, utilizing a standing wheelchair has never been easier.

f5-suspension

AUTOMATIC ANTI-TIPPERS

The F5 Corpus VS' powered anti-tippers are attached directly to the chassis and automatically deploy during the stand sequence, providing the most stable standing platform available, no matter the angle.

UNPRECEDENTED FUNCTIONALITY

With features like programmable power footplates and standing backrest angle adjustments all while retaining 50º of tilt,
the F5 Corpus VS stands without compromise.

F5 VS SPECIFICATIONS

Maximum User Weight 300lbs 136 kg
Maximum Speed Options 7.5 mph 12 km/h
Driving Range (1) 16 miles 26 km
Base Width 25.5" 648 mm
Base Length 38" (42" w/ anti-tippers) 965/1066 mm
Minimum Turning Radius 30" 762 mm
Ground Clearance 3" 75 mm
Optional Seat Elevator 14" 350 mm
Battery Type Group 24 Gel

1 This represents the theoretical driving range when testing the wheelchair according to RESNA WC-2, Section 4. This test is performed under ideal conditions and actual range will vary depending on battery and driving conditions.

Drive Electronics R-net 120A
Seat to Floor Height 17.5", 18.5", 19.5" 445, 470, 495 mm
Power Tilt Options 0° - 50° Posterior 5°, 10°, 20° & 45° Anterior
Recline Options 85º-120°  (manual), 85º-180° (power)
Legrest Elevation 85°  - 170°
Armrest Pad Lengths 10", 13", 16" & 18"
Seat Widths 17" - 23" (by 2" increments) 420 - 570 mm
Seat Depths 14" - 22" (by 1" increments) 370 - 570 mm
Backrest Heights 23" - 28" (by 1" incr.)

580 - 710 mm

**These specifications are dependent on the configuration of the wheelchair




Call for pricing

This product is only available upon request. Contact us for a quote.
